Felt Ceiling Tiles
Echsorbix ® Felt Ceiling Tiles
Echsorbix® Felt Ceiling Tiles are crafted to combine aesthetic elegance with exceptional acoustic functionality. These premium felt panels are designed not only to enhance the visual appeal of any space but also to optimize sound quality by reducing noise and echoes. Versatile in their application, these tiles can be configured as baffles, clouds, or custom designs, making them perfect for a sophisticated yet functional interior design.
- NRC, 9 mm
- 0.30
- Standard thickness
- 9 mm, 12 mm, 18 mm, 24 mm (±5%)
- Panel size
- 600 x 600 mm and 1200 x 600 mm, custom sizes available
- Density grades
- EchoCore 15: 1500 GSM | EchoPro 18: 1800 GSM | EchoMax 22: 2200 GSM
- Areal weight
- 1200 to 3600 GSM (custom)
- Material
- 100% PET polyester fibre, non-woven
Enquiries answered within 48 hours. BOQ, specification and drawing support for project quantities.
01 / The product
Echsorbix ® Felt Ceiling Tiles
-
Features
- Dynamic Design Flexibility: Easily configured as baffles, clouds, or unique shapes to suit various design needs and acoustic requirements.
- Superior Sound Absorption: With a Noise Reduction Coefficient (NRC) of 0.40, these panels efficiently absorb ambient noise, enhancing the acoustic quality of any space.
- Elegant Installation: Tiles can be elegantly suspended from ceilings using brass attachments, adding a touch of luxury while ensuring secure and stable installation.
- Safety and Sustainability: Meeting the highest safety standards, these fire-rated, water-resistant, antimicrobial, odorless, and VOC-free tiles ensure a secure and environmentally friendly choice.
-
Applications
- Commercial Spaces: Transform office environments, conference rooms, or any business setting with tailored acoustic solutions that reduce noise and enhance aesthetic appeal.
- Educational Facilities: Improve concentration and reduce distractions in classrooms and libraries with customizable acoustic configurations.
- Healthcare Settings: Utilize in hospitals and clinics to create quieter, more serene environments that contribute to patient well-being.
- Residential Areas: Ideal for home theaters and living rooms, where acoustics enhance the entertainment experience, or in bedrooms where tranquility is key.
- Hospitality Venues: Upgrade the guest experience in hotels and restaurants by improving both the visual and auditory environment.
Enhance any space with the sophistication and functional elegance of Echsorbix® Felt Ceiling Tiles, engineered for aesthetic flexibility and superb acoustic performance.
02 / Specifications
Technical specifications
| Material | 100% PET polyester fibre, non-woven |
|---|---|
| Manufactured by | MMTPL (Mahabir Multi Tech Pvt. Ltd.), Palwal Plant, Haryana, India |
| Standard thickness | 9 mm, 12 mm, 18 mm, 24 mm (±5%) |
| Custom thickness | 4 mm to 24 mm |
| Panel size | 600 x 600 mm and 1200 x 600 mm, custom sizes available |
| Areal weight | 1200 to 3600 GSM (custom) |
| Density grades | EchoCore 15: 1500 GSM | EchoPro 18: 1800 GSM | EchoMax 22: 2200 GSM |
| NRC, 9 mm | 0.30 |
| NRC, 12 mm | 0.40 |
| NRC, 18 mm | 0.50 |
| NRC, 24 mm | 0.60 |
| NRC, 9 mm over 20 mm BassBloc | 0.90 |
| Acoustic test standards | ASTM C423, ISO 354 |
| Fire rating | Class A and Class B (ASTM E84) |
| Flame spread index | 0 |
| Smoke developed index | S1 |
| Water sorption | ASTM C1104-2019 |
| Colourfastness | ISO 105-B02, grade 6 to 7 |
| Recycled content | Minimum 60% |
| Indoor air quality | VOC ≤ 0.5 mg/m³, UL GREENGUARD certified |
| Recyclable | 100% |
| Colours | 40+ standard, custom development available |
| Warranty | 5 year colour fastness |
| Lead time | 3 to 7 days |
| Country of origin | India |
| Mounting type | Lay-in on suspended grid, or direct fix |
| Customisation | CNC-cut shapes and colours |
- Material
High-quality felt
- Thickness Options
Available in 9mm and 18mm to accommodate different acoustic and aesthetic preferences.
- Installation Method
Designed for versatile mounting, including direct attachment or suspension via elegant brass fittings that complement any decor.
- Color Options
Available in over 20 shades, providing ample choice for matching any interior palette.
03 / Test reports
Tested, documented, on record
Acoustic and fire test reports are issued with project supply. The full set of reports and certificates is listed on the certifications page.
