Products > Acoustic & Echo Treatment > Acoustic Foams & Bass Traps > Groove

...

Groove

Groove Acoustic Foam

Introducing the Groove Acoustic Foam by MMT Acoustix, a cutting-edge acoustic solution designed with a rail track-inspired profile that maximizes sound absorption through a turbo-like double-layered structure. Featuring both a base layer and a top canopy, this design ensures enhanced sound diffusion and superior absorption performance, making it an ideal choice for critical acoustic environments.

NRC
0.90 at 50 mm
Thickness
25 mm, 50 mm, 100 mm (customisable to 800 mm)
Panel size
1800 x 900 mm (6 x 3 ft) and 305 x 305 mm (12 x 12 in)
Size tolerance
±5%
Density
32 to 50 kg/m³
Material
High-density open-cell polyurethane acoustic foam
Request a quote Order a sample

Enquiries answered within 48 hours. BOQ, specification and drawing support for project quantities.

01 / The product

Groove Acoustic Foam

  • Standards

    • Fire Retardant: Certified Class HS1, as per UL94 Standards
    • Eco-Friendly: Made from non-toxic, sustainable materials

  • Key Features

  • 1. Rail Track Design

    The Groove Acoustic Foam features a rail track-inspired pattern that creates multi-layered sound diffusion pathways. This design effectively disrupts and disperses sound waves, preventing unwanted echoes and reflections.

  • 2. Turbo Double Absorption

    With a unique double-layer design, a base layer and a top canopy, the foam absorbs sound at multiple points of contact. This dual-action mechanism enhances both low-frequency absorption and high-frequency control, ensuring a well-balanced acoustic environment.

  • 3. Enhanced Noise Reduction

    The precision-engineered design maximizes surface area for sound absorption, making it effective in controlling reverb, flutter echoes, and unwanted noise reflections.

  • 4. Certified NRC of 0.90

    Compliant with ASTM C423 Standards, the Groove Acoustic Foam boasts an impressive Noise Reduction Coefficient (NRC) of 0.90, absorbing 90% of ambient noise and ensuring exceptional sound clarity.

  • 5. Versatile Applications

    The Groove Acoustic Foam excels in diverse environments, including:

    • Recording Studios
    • Broadcast Rooms
    • Home Theatres
    • Jamming Rooms
    • Offices
    • Podcast Studios

    Whether it’s controlling sound in a professional recording space or enhancing acoustics in a personal setup, the Groove Foam delivers outstanding results.

02 / Specifications

Technical specifications

MaterialHigh-density open-cell polyurethane acoustic foam
Manufactured byMMTPL (Mahabir Multi Tech Private Limited), Palwal Plant, Haryana, India
Panel size1800 x 900 mm (6 x 3 ft) and 305 x 305 mm (12 x 12 in)
Thickness25 mm, 50 mm, 100 mm (customisable to 800 mm)
Density32 to 50 kg/m³
NRC0.90 at 50 mm
Acoustic test standardASTM C423
Fire ratingUL 94 Class HS1 fire retardant available on request; standard grade supplied non-FR
ColoursCharcoal Black, European Blue, MMT Orange, Stone White, Wine, Fire Red
Size tolerance±5%
InstallationDirect adhesive (Turbo® SR Adhesive or spray adhesive) onto clean wall, wood, plaster, metal or glass
Country of originIndia
  • Material

    High-density polyurethane foam

  • Size

    6x3 feet / 1.8x0.9m and 12" x 12" x 2" (customizable options available)

  • Density

    32kg/m³ to 50kg/m³

  • Thickness

    25mm, 50mm, 100mm (customizable up to 800mm)

  • Color Options

    a) Charcoal Black, b) European Blue, c) MMT Orange, d) Stone White, e) Wine, f) Fire Red

  • Noise Reduction Coefficient (NRC)

    0.90 as per ASTM C423 Standards

  • Durability

    Resistant to wear, deformation, and long-term use

03 / In projects

The product in real interiors

...
...
...

GET EXPERT ADVICE

Need Help Choosing Groove Acoustic Foam?

Tell us the space, the area you are covering and the finish you want. Our team will confirm specification, pricing and lead time for your project.

Email Us

Frequently Asked Questions

Who manufactures Groove Acoustic Foam in India?

MMTPL (Mahabir Multi Tech Private Limited) manufactures it at its Palwal plant in Haryana, India, and supplies studios, offices, cinemas and industrial sites in India and 25+ export markets.

What is the NRC of Groove Acoustic Foam?

Groove Acoustic Foam has an NRC of 0.90 at 50 mm, measured to ASTM C423. NRC is a single-figure average, so match the thickness to the frequency you need to control: thicker foam works lower down the spectrum.

What density is the foam?

The foam is high-density open-cell polyurethane at 32 to 50 kg/m3, which is what gives it absorption at mid and high frequencies rather than just at the top end.

Is the foam fire rated?

Standard grade is supplied non-FR. A UL 94 Class HS1 fire retardant grade is available on request, which is what most institutional, government and tender projects specify.

How is it installed?

It bonds directly to a clean wall with Turbo SR Adhesive or spray adhesive, on paint, wood, plaster, metal or glass. No frame or sub-structure is needed.

What colours are available?

Six standard colours: Charcoal Black, European Blue, MMT Orange, Stone White, Wine and Fire Red. Custom colours can be developed for volume orders.
